Anti-Mouse CD45 Antibody, Clone 30-F11

Rat monoclonal IgG2b antibody against mouse CD45
概要
The 30-F11 antibody reacts with an extracellular epitope found on all isoforms and both alloantigens (CD45.1 and CD45.2) of mouse CD45, a type I transmembrane glycoprotein expressed on the surface of most hematopoietic cells except mature erythrocytes, platelets and plasma cells; expression of CD45 is lost during differentiation of these cell types. CD45 is a member of the protein tyrosine phosphatase family and functions in a number of immunoregulatory processes, including cell activation, growth, differentiation and oncogenic transformation. The large cytoplasmic portion of CD45 contains two tyrosine phosphatase domains, one which is enzymatically active, that are involved in modulating the function of intracellular substrates such as the Src kinases Lck and Fyn. Several isoforms of CD45 have been identified, the expression of which differs according to cell type and functional status. Alternative splicing of three exons (4, 5, 6) encoding the extracellular RA, RB and RC polypeptide sequences gives rise to up to 8 isoforms with molecular masses in the range of 180 - 240 kDa.
Subtype
Primary Antibodies
Target Antigen
CD45
Alternative Names
LCA, Leukocyte common antigen, Ly-5, Protein tyrosine phosphatase receptor type C, PTPRC, T200
Reactive Species
Mouse
Conjugation
Alexa Fluor 488, APC, Biotin, FITC, PE, PerCP-Cyanine5.5, Unconjugated
Host Species
Rat
Cell Type
Granulocytes and Subsets, Hematopoietic Stem and Progenitor Cells, Lymphocytes, Myeloid Cells
Species
Mouse
Application
CyTOF, Flow Cytometry, Functional Assay, Immunocytochemistry, Immunofluorescence, Immunohistochemistry, Immunoprecipitation, Western Blotting
Area of Interest
Immunology
Clone
30-F11
Gene ID
19264
Isotype
IgG2b, kappa
数据及文献

Data

Data for Unconjugated

Figure 1. Data for Unconjugated

Flow cytometry analysis of C57BL/6 mouse splenocytes labeled with Anti-Mouse CD45 Antibody, Clone 30-F11, followed by a mouse anti-rat IgG2b antibody, FITC (filled histogram), or Rat IgG2b, kappa Isotype Control Antibody, Clone RTK4530 (Catalog #60077), followed by a mouse anti-rat IgG2b antibody, FITC (solid line histogram).

Data for Alexa Fluor® 488-Conjugated

Figure 2. Data for Alexa Fluor® 488-Conjugated

Flow cytometry analysis of C57BL/6 mouse splenocytes labeled with Anti-Mouse CD45 Antibody, Clone 30-F11, Alexa Fluor® 488 (filled histogram) or Rat IgG2b, kappa Isotype Control Antibody, Clone RTK4530, Alexa Fluor® 488 (Catalog #60077AD) (solid line histogram).

Data for APC-Conjugated

Figure 3. Data for APC-Conjugated

Flow cytometry analysis of C57BL/6 mouse splenocytes labeled with Anti-Mouse CD45 Antibody, Clone 30-F11, APC (filled histogram) or Rat IgG2b, kappa Isotype Control Antibody, Clone RTK4530, APC (Catalog #60077AZ) (solid line histogram).

Data for Biotin-Conjugated

Figure 4. Data for Biotin-Conjugated

Flow cytometry analysis of C57BL/6 mouse splenocytes labeled with Anti-Mouse CD45 Antibody, Clone 30-F11, Biotin, followed by streptavidin (SAV) APC (filled histogram), or Rat IgG2b, kappa Isotype Control Antibody, Clone RTK4530, Biotin (Catalog #60077BT), followed by SAV APC (solid line histogram).

Data for FITC-Conjugated

Figure 5. Data for FITC-Conjugated

Flow cytometry analysis of C57BL/6 mouse splenocytes labeled with Anti-Mouse CD45 Antibody, Clone 30-F11, FITC (filled histogram) or Rat IgG2b, kappa Isotype Control Antibody, Clone RTK4530, FITC (Catalog #60077FI) (solid line histogram).

Data for PE-Conjugated

Figure 6. Data for PE-Conjugated

Flow cytometry analysis of C57BL/6 mouse splenocytes labeled with Anti-Mouse CD45 Antibody, Clone 30-F11, PE (filled histogram) or Rat IgG2b, kappa Isotype Control Antibody, Clone RTK4530, PE (Catalog #60077PE) (solid line histogram).

Data for PerCP-Cy55-Conjugated

Figure 7. Data for PerCP-Cy55-Conjugated

Flow cytometry analysis of C57BL/6 mouse splenocytes labeled with Anti-Mouse CD45 Antibody, Clone 30-F11, PerCP-Cy5.5 (filled histogram) or a rat IgG2b, kappa PerCP-Cy5.5 isotype control antibody (solid line histogram).
